JH-100-S
POLO Series 51.2V 100AH battery
Model: JH-100-S
Key Features
- Suitable for grid-tied and off-grid
- Compatible with various mainstream inverters
- One-key parallel switch
- Secondary release design protection
- 6000 cycles @25℃ 50A charge/discharge
The JH-100-S is part of BANAVE’s Home Energy Storage range — pOLO Series 51.2V 100AH battery. Contact us for datasheets, certification documents and OEM/ODM options.
Specifications
| Model | JH-100-S |
|---|---|
| Nominal Voltage | 51.2V |
| Rated Capacity | 100AH |
| Operating Voltage | 42V-58.4V |
| Standard Charging Current | 50A/100A |
| Maximum Charge/Discharge Current | 100A |
| Operating Temperature Range | 0-40°C (charging) -20-40°C (discharging) |
| Storage Temperature | -10°C~35°C (1 month) 25±2°C (3 months) 65%±20% RH |
| Cycle Life | 6000 cycles @25°C 50A charge/discharge current 70% standard capacity 80% |
| Communication | CAN & RS485 |
| Protection Level | IP20 |
| Humidity Range | 5~95% |
| Net Dimensions | 618*450*208.5MM |
| Net Weight | 48±3KG |
